CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
Range
[Factory Setting]
Parameter Description / Notes
P000 0 to 999
Access [ 0 ]
Parameter 1
6.3.1 Access and Read Only Parameters - P000 to P099
P002 0 to 999
Frequency [ - ]
Proportional Value 0.01 (< 10.0);
0.1 (< 100);
1 (> 99.9)
P003 0 to 1.5 x I
nom
Motor Current [ - ]
(Output) 0.1 A
P004 0 to 524
DC Link Voltage [ - ]
1 V
Releases the access to change the parameter values.
The password is 5.
The use of the password is always active.
Indicates the value of P208 x P005.
In case of different scales and units, use P208.
Indicates the inverter output current in ampères. (A).
Indicates the inverter DC Link voltage in volts (V).
P005 0 to 300
Motor Frequency [ - ]
(Output) 0.1 (< 100);
1 (> 99.9)
Indicates the inverter output frequency in hertz (Hz).
P007 0 to 240
Motor Voltage [ - ]
(Output) 1 V
Indicates the inverter output voltage in volts (V).
P008 25 to 110
Heatsink [ - ]
Temperature 1
o
C
Indicates the current power at the heatsink in Celsius
degrees (°C).
The inverter overtemperature protection (E04) acts
when heatsink temperature reaches 103 ºC.
P014 00 to 41
Last Fault [ - ]
-
Indicates the code of the last occured fault.
Section 7.1 shows a list of possible faults, their code
numbers and possible causes.
P015 00 to 41
Second Fault [ - ]
Occurred -
Indicates the code of the last occured fault.
Section 7.1 shows a list of possible faults, their code
numbers and possible causes.
P016 00 to 41
Third Fault [ - ]
Occurred -
Indicates the code of the last occured fault.
Section 7.1 shows a list of possible faults, their code
numbers and possible causes.
P023 x.yz
Software Version [ - ]
Indicates the software version installed in the DSP
memory located on the control board.
