CFW-10 - QUICK PARAMETER REFERENCE
Readonly
Parameter
Parameter Function
Adjustable Range
Factory
Unit
User
Page
Setting Setting
Fx and Ix
P288 Fx Frequency 0.0 to P134 3.0 Hz 85
P290 Ix Current 0.0 to 1.5 x I
nom
P295 A 85
Inverter Data
P295 Rated Inverter 1.6 A 85
Current (I
nom
) 2.6
4.0
7.3
10.0
15.2
P297
(1)
Switching Fraquency 2.5 to 15.0 5.0
(4)
kHz 86
DC Braking
P300 DC Braking Time 0.0 to 15.0 0.0 s 86
P301 DC Braking Start Frequency 0.0 to 15.0 1.0 Hz 86
P302 Braking Torque 0.0 to 100 50.0 % 86
SPECIAL FUNCTION - P500 to P599
PID Regulator
P520 PID Proportional Gain 0.0 to 999 100 % 94
P521 PID Integral Gain 0.0 to 999 100 % 94
P522 PID Differential Gain 0.0 to 999 0 % 94
P525 PID Regulator Set point 0.0 to 100 0 % 94
via keypad
P526 Process Variable Filter 0.0 to 10.0 0.1 s 94
P527 PID Regulator Action Type 0 = Direct 0 - 94
1 = Reverse
P528 Proc. Var. Scale Factor 0 to 999 100 - 95
P536 Automatic Setting of P525 0 = Active 0 - 95
1 = Inactive
(1) This parameter can be changed only with the inverter disabled (stopped motor).
(2) This Parameter cannot be changed whentheroutine"load factory default" is excuted (P204 = 5).
(3) 6 % for the 15.2 A model.
(4) 2.5 kHz for the 15.2 A model.
Display Description Page
E00 Output Overcurrent/Short-Circuit 96
E01 DC Link Overvoltage 96
E02 DC Link Undervoltage 96
E04 Inverter Overtemperature 97
E05 Output Overload (I x t function) 97
E06 External Fault 97
E08 CPU Error (watchdog) 97
E09 Program Memory Error (checksum) 97
E24 Programming Error 97
E31 Keypad (HMI) Communication Fault 97
E41 Self-Diagnosis Error 97
II. Fault Messages
III. Other Messages
Display Description
rdy Inverter is ready to be enabled
Sub
Power supply voltage is too low for the inverter
operation (undervoltage)
dcb Inverter in DC braking mode
EPP Inverter is loading factory setting
