10
CFW-10 - QUICK PARAMETER REFERENCE
Parameter Function
Adjustable Range
Factory
Unit
User
Page
Setting Setting
P231
(1)
Forward/Reverse 0 = Forward 2 - 75
Selection 1 = Reverse
2 = Commands
Analog Inputs(s)
P234 Analog Input AI1 Gain 0.0 to 999 100 % 75
P235
(1)
Analog Input AI1 Signal 0 = (0 to 10) V/ (0 to 20) mA 0 - 78
1 = (4 to 20) mA
P236 Analog Input AI1 Offset -120 to +120 0 % 78
P238 Input Gain(HMIPotentiometer) 0.0 to 999 100 % 78
P240 Input Offset(HMIPotentiometer) -120 to +120 0 % 78
P248 Analog Input (AI1) Filter 0 to 200 200 ms 78
Time Constant
Digital Inputs
P263
(1)
Digital Input DI1 0 = No Function 1 - 78
Function 1 = No Function or
P264
(1)
Digital Input DI2 General Enable 5 - 78
Function 2 = General Enable
P265
(1)
Digital Input DI3 3 = JOG 6 - 78
Function 4 = Start/Stop
P266
(1)
Digital Input DI4 5 = Forward/Reverse 4 - 79
Function 6 = Local/Remote
7 = Multispeed
8 = Multispeed using
Ramp2
9 = Forward
10 = Reverse
11= Forward with Ramp 2
12 = Reverse with Ramp 2
13 = On
14 = Off
15 = Activates ramp 2
16 = Accelerates EP
17 = Decelerates EP
18 = Acclerates EP with
Ramp2
19 = Decelerates EP with
Ramp2
20 = Without External Fault
21 = Error Reset
22 = Start/Accelerate EP
23 = Decelerate EP/Stop
24 = Stop
25 = Security Switch
26 = Frequency Input
27 = Manual/Automatic
(PID)
P271 Frequency Input Gain 0.0 to 999 200 % 84
DigitalOutputs
P277
(1)
Relay Output RL1 Function 0 = Fs > Fx 7 - 84
1 = Fe > Fx
2 = Fs = Fe
3 = Is > Ix
4 and 6 = Not Used
5 = Run
7 = Not Fault
