CFW-10 - QUICK PARAMETER REFERENCE
Parameter Function
Adjustable Range
Factory
Unit
User
Page
Setting Setting
V/F Control
P136 Manual Torque Boost 0.0 to 100 20.0
(3)
% 66
(I x R Compensation )
P137 Automatic Torque Boost 0.0 to 100 0.0 % 67
(Automatic Ix R Compensation)
P138 Slip Compensation 0.0 to 10.0 0.0 % 68
P142
(1) (2)
Maximum Output Voltage 0.0 to 100 100 % 69
P145
(1) (2)
Field Weakening P133 to P134 60.0 Hz 69
Frequency (F
nom
)
DC Link Voltage Regulation
P151 Actuation Level of the Voltage Model 100: 360 to 460 430 V 69
Regulation at the DC Link Model 200: 325 to 410 380
(Intermediary Circuit)
Overload Current
P156
(2)
Motor Overload Current 0.3 x I
nom
to 1.3 x I
nom
1.2 x P295 A 70
Current Limitation
P169
(2)
Maiximum Output Current 0.2 x I
nom
to 2.0 x I
nom
1.5 x P295 A 71
CONFIGURATION PARAMETERS - P200 to P398
Generic Parameters
P202
(1)
Control Mode 0 = Linear V/F Control 0 - 71
1 = Quadratic V/F Control
P203 Special Functions Selection 0 = None 0 - 73
1 = PID Regulator
P204
(1)
Load Parameters with 0 to 4 = Not used 0 - 73
Factory Setting 5 = Load Factory Default
6 to 999 = Not used
P206 Auto-Reset Time 0 to 255 0 s 73
P208 Reference Scale Factor 0.0 to 100 1.0 - 73
P219
(1)
Starting Point of the Switching 0.0 to 15.0 15.0 Hz 73
Frequency Reduction
Local/Remote Definition
P221
(1)
Speed Reference 0 = HMI Keys / - 74
Selection – Local Mode 1 = AI1
2 = EP
3 = HMI Potentiometer
4 to 5 = Reserved
6 = Multispeed
7 = Frequency Input
P222
(1)
Speed Reference Selection - 0 = HMI Keys / 1 - 74
Remote Mode 1 = AI1
2 = EP
3 = HMI Potentiometer
4 to 5 = Reserved
6 = Multispeed
7 = Frequency Input
P229
(1)
Command Selection - 0 = HMI Keypad 0 - 74
Local Mode 1 = Terminals
P230
(1)
Command Selection - 0 = HMI Keypad 1 - 74
Remote Mode 1 = Terminals
0 = For
Inverters
Standard
and Clean
Versions
3 = For
Inverters
Plus
Version
