20
CHAPTER 2 - GENERAL INFORMATION
NOTE!
The Option field (S or O) defines if the CFW-10 is a standard version or if it will be equipped with any optional devices.
If the standard version is required, the specification code ends here.
The model number has always the letter Z at the end. For example:
CFW100040S2024ESZ = standard 4.0 A CFW-10 inverter, single-phase at 200 V to 240 V input with manual in
English.
If the CFW-10 is equipped with any optional devices, you must fill out all fields in the correct sequence up to the last
optional device, the model number is completed with the letter Z.
HOW TO SPECIFY THE CFW-10 MODEL
CFW-10 0040 S 2024 P O _ _ _ _ _ _ _ _ Z
Special
Software
Blank =
standard
End
Code
Special
Hardware
Blank =
standard
Rated
Output
Current for
220 to 240 V:
0016 = 1.6 A
0026 = 2.6 A
0040 = 4.0 A
0073 = 7.3 A
0100 = 10.0 A
0152 = 15.2 A
110 to 127 V:
0016 = 1.6 A
0026 = 2.6 A
0040 = 4.0 A
Number of
phases of
the power
supply
S = single-
phase
T = three-
phase
Manual
Language:
P = Portuguese
E = English
S = Spanish
G = German
Power
supply:
2024 =
200 to 240 V
1112 =
110 to 127 V
Options:
S = standard
O = with
options
WEG
Series 10
Frequency
Inverter
Control
Board:
Blank =
standard
control
CL = Clean
PL = Plus
Built-in EMC
filter:
Blank =
standard
FA = with
EMC (class A)
filter
CP = Cold
Plate
heatsink
version
