WEG CFW-10 - Page 23

23
CHAPTER 3 - INSTALLATION AND CONNECTION
Figure 3.1 - Dimensional of CFW-10 - Sizes 1, 2 and 3
Size 2
Size 3
Size 1
Table 3.1 a) Installation data (dimensions in mm (in)) – Refer to Section 9.1
Dimensions Fixing Base
Model
Width
L
[mm]
(in)
Height
H
[mm]
(in)
Depth
P
[mm]
(in)
A
[mm]
(in)
B
[mm]
(in)
C
[mm]
(in)
D
[mm]
(in)
Mounting
Screw
Weight
[kg]
(lb)
Degr ee of
Protection
SINGLE-PHASE
1.6 A /
200-240 V
95
(3.74)
132
(5.20)
121
(4.76)
85
(3.35)
120
(4.72)
5
(0.2)
6
(0.24)
M4 0.9
(1.98)
IP20
2.6 A /
200-240 V
95
(3.74)
132
(5.20)
121
(4.76)
85
(3.35)
120
(4.72)
5
(0.2)
6
(0.24)
M4 0.9
(1.98)
IP20
4.0 A /
200-240 V
95
(3.74)
132
(5.20)
121
(4.76)
85
(3.35)
120
(4.72)
5
(0.2)
6
(0.24)
M4 0.9
(1.98)
IP20
7.3 A /
200-240 V
115
(4.53)
161
(6.34)
122
(4.8)
105
(4.13)
149
(5.83)
5
(0.2)
6
(0.24)
M4 1.5
(3.31)
IP20
10.0 A /
200-240 V
115
(4.53)
191
(7.46)
122
(4.8)
105
(4.13)
179
(7.05)
5
(0.2)
6
(0.24)
M4 1.8
(3.96)
IP20
1.6 A /
110-127 V
95
(3.74)
132
(5.20)
121
(4.76)
85
(3.35)
120
(4.72)
5
(0.2)
6
(0.24)
M4 0.9
(1.98)
IP20
2.6 A /
110-127 V
95
(3.74)
132
(5.20)
121
(4.76)
85
(3.35)
120
(4.72)
5
(0.2)
6
(0.24)
M4 0.9
(1.98)
IP20
4.0 A /
110-127 V
115
(4.53)
161
(6.34)
122
(4.8)
105
(4.13)
149
(5.83)
5
(0.2)
6
(0.24)
M4 1.5
(3.31)
IP20
THREE-PH ASE
1.6 A /
200-240 V
95
(3.74)
132
(5.20)
121
(4.76)
85
(3.35)
120
(4.72)
5
(0.2)
6
(0.24)
M4 0.9
(1.98)
IP20
2.6 A /
200-240 V
95
(3.74)
132
(5.20)
121
(4.76)
85
(3.35)
120
(4.72)
5
(0.2)
6
(0.24)
M4 0.9
(1.98)
IP20
4.0 A /
200-240 V
95
(3.74)
132
(5.20)
121
(4.76)
85
(3.35)
120
(4.72)
5
(0.2)
6
(0.24)
M4 0.9
(1.98)
IP20
7.3 A /
200-240 V
95
(3.74)
132
(5.20)
121
(4.76)
85
(3.35)
120
(4.72)
5
(0.2)
6
(0.24)
M4 0.9
(1.98)
IP20
10.0 A /
200-240 V
115
(4.53)
161
(6.34)
122
(4.8)
105
(4.13)
149
(5.83)
5
(0.2)
6
(0.24)
M4 1.5
(3.31)
IP20
15.2 A /
200-240 V
115
(4.53)
191
(7.46)
122
(4.8)
105
(4.13)
179
(7.05)
5
(0.2)
6
(0.24)
M4 1.8
(3.96)
IP20
