42
CHAPTER 3 - INSTALLATION AND CONNECTION
Note: Maximum switching frequency is 5 kHz.
Table 3.5.2 - List of frequency drive models, EMC filters and EMC categories
NOTE!
The CFW-10 inverters with three-phase supply do not have EMC
filters.
Inverter Model
(single-phase)
Input RFI
Filter
EMC Class
1.6 A / 200-240 V
2.6 A / 200-240 V
4.0 A / 200-240 V
1.6 A / 110-127 V
2.6 A / 110-127 V
Footprint / Booksize
Model:
B84142A0012R212
(EPCOS)
Standard Model:
B84142-A20-R
(EPCOS)
Class A1.
Maximum motor cable length is 30 meters (98.4 ft).
Class A2.
Maximum motor cable length is 50 meters (164 ft).
Class B.
Maximum motor cable length is 5 meters (16.4 ft).
7.3 A / 200-240 V
4.0 A / 110-127 V
Footprint / Booksize
Model:
B84142B18R212
(EPCOS)
Class A1.
Maximum motor cable length is 30 meters (98.4 ft).
Class A2.
Maximum motor cable length is 50 meters (164 ft).
Class B.
Maximum motor cable length is 5 meters (16.4 ft).
7.3 A / 200-240 V
4.0 A / 110-127 V
(EPCOS)
Standard Model:
B84142-A20-R
(EPCOS)
Class A1.
Maximum motor cable length is 25 meters (82 ft).
Class A2.
Maximum motor cable length is 40 meters (131.2 ft).
Class B.
Maximum motor cable length is 5 meters (16.4 ft).
10.0 A / 200-240 V
Footprint / Booksize
Model:
B84142B22R212
(EPCOS)
Class A1.
Maximum motor cable length is 30 meters (98.4 ft).
Class A2.
Maximum motor cable length is 40 meters (131.2 ft).
Class B.
Maximum motor cable length is 5 meters (16.4 ft).
10.0 A / 200-240 V
Standard Model:
B84142-A30-R
(EPCOS)
Class A1.
Maximum motor cable length is 30 meters (98.4 ft).
Class A2.
Maximum motor cable length is 50 meters (164 ft).
Class B.
Maximum motor cable length is 3 meters (9.8 ft).
