WINDSOR
4•111
The burner grate is attached to the cooktop cover by two spring
clips located on the underside of the cooktop cover. The burner
grate can be separated from the cooktop cover for cleaning
purposes. Place a towel down onto the countertop next to the
cooktop. Lift the cooktop cover up by the front corners, just high
enough to clear the top of the burners. Pull the cooktop cover
toward the front of the cooktop and lift it away. Place the cooktop
cover upside down onto the towel. Squeeze both of the grate
spring clips to remove the grate from cooktop cover.
WARNING: If you smell gas, extinguish all open
flames and turn off the main gas supply. Liquid
propane is highly volatile, highly explosive and
extremely dangerous. Explosion, fire, property dam-
age, injury or death can result. Propane is a “heavy”
gas and will lay on the floor and “hide” in corners.
Open all windows and doors. Do not touch any elec-
trical switches. They may cause a spark which can
ignite. Contact a qualified service center to have the
problem correctly diagnosed and repaired before
resuming operation.
1. A yellow flame is an indication of incorrect fuel/air ratio. Lowered
BTU output and carbon build up can occur.
2. When cooking at an altitude above 5,000 feet the flame may change
appearance and the flame BTU output will be lowered. Allow extra
cooking time.
3. Do not allow the tips of the flame to extend beyond pan or pot edge.
When this occurs heat is wasted and possibility of injury increases.
4. Pre-heat the oven for 10 minutes prior to use.
• Clean all surfaces as soon as possible after boil overs or spillovers.
• Use warm soapy water to clean the burner grates, cooktops, painted
surfaces, porcelain surfaces, stainless steel surfaces and plastic items
on your range or cooktop. Grit or acid-type cleaners may ruin the
surface.
• Use only non-abrasive plastic scrubbing pads.
• Do not allow foods containing acids (such as lemon or tomato juice
or vinegar) to remain on porcelain or painted surfaces. Acids may
remove the glossy finish. Wipe up egg spills when cooktop is cool.
• Allow porcelain surfaces to cool before cleaning. Burns from the
heated surface may occur or the cooktop porcelain can crack.
Burner Grate
Cleaning &
Maintenance
Tips
