Driving & Safety
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2•57
Dual Rear Wheels:
Slide the inner dual wheel over the studs, being careful not to damage the
stud threads. Align the handholds for valve access and slide the outer dual
wheel over the studs, again being careful not to damage the stud threads.
Snug the nuts in sequence, do not tighten them fully until all have been
seated. Tighten the nuts to 500 ft. lbs. using the sequence as shown in the
illustration. The hub mount wheels use two piece flange cap nuts for both
front and rear applications. No inner cap nuts are required.
Torque the Nuts Properly:
• Be sure to tighten the wheel nuts to the recommended nut torque. Do
not over tighten.
• Maintain the nut torque at the recommended level through planned
periodic checks or at 10,000 miles intervals, whichever comes first.
• If air wrenches are used, they must be periodically calibrated for the
proper torque output. Use a torque wrench to check the air wrench
output and adjust the line pressure for the correct torque.
WINDSOR
WEIGHTS 40PBD 40PBDS 40PBDD 40PWD 40PKD 40PKDD
Gross Vehicle Weight Rating 35,800 lbs 35,800 lbs 35,800 lbs 35,800 lbs 35,800 lbs 35,800 lbs
Gross Combined Weight Rating 45,800 lbs 45,800 lbs 45,800 lbs 45,800 lbs 45,800 lbs 45,800 lbs
Front Gross Axle Weight Rating 12,800 lbs 12,800 lbs 12,800 lbs 12,800 lbs 12,800 lbs 12,800 lbs
Rear Gross Axle Weight Rating 23,000 lbs 23,000 lbs 23,000 lbs 23,000 lbs 23,000 lbs 23,000 lbs
MEASUREMENTS 40PBD 40PBDS 40PBDD 40PWD 40PKD 40PKDD
Wheelbase 270" 270" 270" 270" 270" 270"
Overall Length 40' 10" 40' 10" 40' 10" 40' 10" 40' 10" 40' 10"
Overall Height 11' 11" 11' 11" 11' 11" 11' 11" 11' 11" 11' 11"
Interior Height 79" 79" 79" 79" 79" 79"
Interior Width 96" 96" 96" 96" 96" 96"
Exterior width (100.5" floorplan) 100.5" 100.5" 100.5" 100.5" 100.5" 100.5"
SPECIFICATIONS CHART
- DIMENSIONS CHART
