The air filter minder is a precision overflow restriction gauge designed to
take the guesswork out of air cleaner replacement. The air filter minder is
located in the engine rear compartment. Operation is simple and virtually
foolproof. As dirt captured by filter cartridge slowly builds up the system
pressure drop increases and is indicated by the filter minder on an easy to
read scale. The indicator locks up at the point of maximum restriction so
readings can be taken with or without the engine running. When the desired
change-out point is reached, the air filter should be replaced and the service
indicator is easily reset by pushing the button at the bottom of the minder.
When the air filter needs to be changed, the entire air filter cartridge is
discarded and replaced by loosening the inlet and outlet ducting clamps and
releasing the retaining band snaps. The air filter is located in the rear engine
compartment. The air filter is located behind the engine access door.
Chassis Information
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
WINDSOR
10•299
AIR FILTER
MINDER
AIR FILTER -
Changing
