To enter programming mode:
• Press and hold the Set-Up buttons (up and down arrows) for
five seconds. The RC7 GS remote will beep.
• Release the buttons. The programming mode has been entered
when the Search Sense is displayed.
• Use the Menu buttons (up and down arrows) to scroll though
available field settings.
• Use the Settings button (arrow pointing to right) to scroll
through available settings for selected field.
To exit the programming mode:
• Allow 20 seconds to elapse from the time the last key is
pressed. Program changes are then accepted by the inverter in
non-volatile memory.
• Momentarily pressing the set-up buttons (up and down arrows)
exits the programming menu. Program changes are automati-
cally saved in non-volatile memory.
• The inverter is now ready to use. “Waiting for AC” will be dis-
played or if any program changes were made with AC applied,
one of the three stages of the charge cycle will be displayed.
NOTE: All electric coaches use two remotes and two inverters.
The remote located in the monitor panel is used to program the
master inverter. The second remote displays only selected menu
items.
NOTE: Non-volatile memory is a permanent programming
change accepted by the inverter. Turning the main battery dis-
connect switches off does not affect programming changes.
Only the inverter clock time and automatic generator start/stop
programming will be erased.
Search Sense:
The inverter searches for an AC load. For example: While inverting, AC
loads of various amperage may be applied. These loads may range from a
few watts to several amps. Search Sense is the cut-in point which the invert-
er will exit the “sleep mode” and start inverting at a standard output voltage.
The Defeat setting allows the inverter to be at a constant standard output
voltage. When changing the Search Sense value, AC loads must be evaluated
for proper inverter operation.
Auto LBCO:
The Automatic Low Battery Cut-off may be turned on or off. These set-
tings allow the inverter to use available DC voltage to a set value while
inverting. Turning the LBCO ON stops the inverter when the battery voltage
drops to 10.5 Volts DC. Turning the LBCO OFF stops the inverter when the
battery voltage drops to 8.5 Volts DC. This leaves the batteries discharged,
but not completely dead.
Electrical Systems - House
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
WINDSOR
8•200
Programming
the RC 7 GS
Adjustable Field
Settings
