from one another. When installing a metal end onto the coax cable, use
care so that none of the woven ground strands come in contact with the
center conductor. A continuity tester is used to test for a suspected bad
coax wire run. Unscrew both ends of the suspected bad coax run and
use the continuity tester to check between the center conductor and out-
side threaded ring. If continuity is present the coax is shorted. To test for
an open connection of a particular coax run, touch ends of the coaxes
ground or center conductor using the tester leads. Continuity should be
present. For proper operation there should be continuity from one end to
the other of both the ground and center conductor. No continuity should
be between the ground and center conductor. Though damage does not
usually occur from a shorted or open coax cable, picture quality is com-
promised.
The motorhome is equipped with a remote control and color television. The
TV operates from 120 volts AC power only, which can be provided by shore power
or converter. Viewing time of the front TV from the converter depends on the state
of charge of the batteries and any additional 12Volt DC lighting being used.
The VCR and bedroom television operate from 120 Volts AC only, which can
be provided by shore power or converter. Use the instructions given in the video
selector box section to use these components.
Located under the dash next to the accessory connector is a two pin connector
labeled Citizens Band Radio. Red wire supplies 12Volt DC and is fused to 2 amps
through front distribution panel. White wire is connected to chassis frame.
The motorhome is equipped with a cell phone mount. The antenna lead is located
behind the dash instrument cluster. To access the lead remove the inspection panel
located on top of the dash pad. The antenna lead run is installed from the roof down
the driver’s side A-pillar. This is the section between the driver’s side window and
the windshield. The coiled antenna lead should be located toward the front firewall,
directly behind the instrument cluster.
The Digital Video Disc Player connection is located only at the front television
set. The front television set must be ON and have input One selected at the televi-
sion. The DVD Player will only be required to have power for the unit and have a
DVD Disc installed. The DVD Player operates from 120 Volt AC powered from the
House electrical system.
Equipment
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
WINDSOR
5•144
Front Television
VCR & Bedroom
Television
CITIZEN BAND
RADIO PREWIRE
CELL PHONE
PREWIRE
DVD PLAYER
(OPTIONAL)
