Appendix
Appendix B: Product Specifications
Model Name
M101M8
Display
Specification
Size
10.1"
Resolution
1280 x 800
Brightness
400 (typ.)
Touch
Projective Capacitive Multi-touch
Panel Viewability
Optical bonding for sunlight viewability
System
Specification
Processor ARM® Cortex™-A53 Octa-Core 1.3GHz
System Memory
2 GB LPDDR3
Storage
16 GB eMMC
Operating System
Android 7.0 Nougat
Wireless
Communications
WLAN
802.11 a/b/g/n
BT
BT 4.1
GPS
GPS / AGPS / GLONASS
WWAN
Optional 4G/ LTE or 3G
System I/O Buttons
Indicators Sensors
Security
Audio
1 x built-in Mic
2 x 1W Speaker
External I/O
1 x Micro USB 2.0 OTG
1 x Line out/Mic in
1 x DC jack
1 x Micro SD Card Slot
Buttons
1 x Power Button
1 x Menu/Home key
1 x Back key
1 x Volume up
1 x Volume down
LED Indicators
1 x Status indicator
Sensors
Light Sensor, Proximity Sensor, G-sensor, Digital
Compass
Data Capture
Camera
Rear: 8 MP Camera with LED auxiliary light (Auto Focus)
Front: 2MP Camera*
*Either one with Barcode Reader
Data Capture
• NFC Reader (Read / Write, Peer to Peer mode)
• Optional 1D/2D Barcode Reader
Mechanical and
Environment
Operating Temp. -20°C ~ +60°C (AC Mode),-10°C ~ +50°C (Battery Mode)
IP Proof
IP65, dustproof and waterproof
Shock
MIL-STD-810G Method 516.6 Procedure I
Vibration
MIL-STD-810G Method 514.6 Procedure I
Drop
MIL-STD-810G Method 516.6, 4 ft
Salt Fog
MIL-STD-810G Method 509.5 Part II
Dimensions
271.67 x 198.2 x 21 mm (10.7 x 7.8 x 0.83 inches)
Weight
0.99 kg (1.98 lbs)
Power Management
Battery 7.4V, typ. 5140 mAh Li-Polymer Battery (2S1P)
Battery How-
Swap Function
Optional hot-swap battery
Battery Operating
Time
Std. Battery: 10 hours*
Adapter 100-240V/ 12V DC 3A
