14.7.2. Controlling Zoom/Focus
To control Zoom and Focus during live image monitoring mode:
- Press the [SELECT] button. Move the “Select” icon to the desired channel.
- Press the [MENU] button.
- Select ‘Zoom/Focus’ from the PTZ Menu.
- Control Zoom and Focus functions using the up, down, left and right arrows of front panel.
14.7.3. Using Load Preset
To load preset for dome camera during live monitoring mode:
- Press the [SELECT] button. Move the “Select” icon to the desired channel.
- Press the [MENU] button.
- Select ‘Load Preset’ from the PTZ Menu.
- Press the number button for desired preset on the front panel.
14.7.4. Using Save Preset
To set a new preset point for dome camera during live monitoring mode:
- Move dome camera to the desired position using the ‘Pan/Tilt’ and ‘Zoom/Focus’ menus.
- Press the [SELECT] button.
- Press the [MENU] button.
- Select ‘Save Preset’ from the PTZ Menu.
- Designate a number for the preset position by pressing a number button on the front panel.
14.8. Using Relay
To set relay on/off. (HVR-16E supports four relay outputs):
- Press the [ACK/RELAY] button.
- The icon “Relay On” shows on the screen.
- Press the relay number button between 1 and 4, and then the related relay out signal will be transmitted.
- In order to set relay off, press the [ACK/RELAY] button again.
- The “Relay On” will show because the relay keeps being set as on.
- Press the [ACK/RELAY] button again, and the icon “Relay Off” will show.
