Basic Configuration DRS5116
Wren
2003. 09. 06 (v 1.0)
85
16.4. Alarm Rec.
This menu isused to configure the settings for alarm recording conditions. To activate this schedule
set:
(1) Turn the “Event Recording” under the “Normal Recording” tab to “On.”
(2) The “Alarm Source” should be set before the alarm recording menu.
16.4.1. Setting Sensor
It is used for settingthe sensor type. The DRS supports Normal Open (N.O.) and Normal Close (N.C.)
types.
Global
Global is ssed to set all sensors to the same condition.
Select: Off/N.O./N.C.and press the “Apply” button.
Configuration
Configuration is used to set each sensor separately
