3. Open the fuser access door, and then remove the jammed paper.
Note: Make sure that all paper fragments are removed.
4. Close door A.
Paper jam in the duplex unit
1. Open door A.
CCAAUUTTIIOONN——HHOOTT SSUURRFFAACCEE:: The inside of the printer might be hot. To reduce the risk of injury from a
hot component, allow the surface to cool before touching it.
Xerox
®
C310 Color Printer User Guide 213
Troubleshoot a Problem
