Xerox COLORQUBE 8570 Service Manual

October 2012
2-9
ColorQube 8570/8870 Service Manual
Testing Clutch, Motor, and Solenoid Resistance
Fault Messages and Codes
Xerox Internal Use Only - Revised, 3rd Revision
Testing Clutch, Motor, and Solenoid Resistance
1. Turn off the printer and disconnect the power cord.
2. With a Digital Multimeter (DMM) set for measuring resistance, test each motor’s windings
for correct resistance (disconnected from the printer). Rotate the motor’s drive shaft
slightly while taking the measurement.
Table 1 Clutch, Motor, and Solenoid Resistance
Clutch, Motor, and
Solenoid
Resistance (approximate)
Head Maintenance Clutch 186 ohms +/- 15%
Paper-Pick Clutch
Deskew Clutch
186 ohms +/- 15%
Process Drive Motor
Media Path Drive Motor
2.85~3.85 ohms (Difficult to measure due to variability at the
brush/commutator interface.)
Tray Lift Motor 50~500 ohms
X-Axis Motor 5.9 ohms/phase +/- 10% (pins 2 to 4 and pins 3 to 5)
Y-Axis Motor 1.05~1.43 ohms (Difficult to measure due to variability at the
brush/commutator interface.)
MPT Pick Solenoid 124 ohms +/- 5%
Ink Loader Solenoid ~10 ohms blue-red, ~10 ohms yellow-red, ~20 ohms blue-yellow
Preheater Lift Solenoid ~18 ohms blue-red, ~18 ohms yellow-red, ~36 ohms blue-yellow

Xerox COLORQUBE 8570 Specifications

General

Print Technology	Solid Ink
Monthly Duty Cycle	Up to 85, 000 pages
First Page Out Time (Color)	As fast as 5 seconds
First Page Out Time (B&W)	As fast as 5 seconds
Memory (Maximum)	1 GB
Output Capacity	350 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 40 ppm color / 40 ppm black
Connectivity	USB 2.0, Ethernet
Print Languages	PCL 6, PostScript 3, PDF
