System Settings
117
For information on the screen keyboard, refer to Cover Page in the Fax chapter of the
User Guide.
Company Logo
Specifies the sender name (company logo). Enter up to 30 characters using the screen
keyboard on the touch screen. The sender name is printed in the [Transmission Header
Text] or [Cover Page].
Machine Password
Specifies a password to restrict the remote machines which can send documents. By
setting a machine password, your machine can accept receiving or polling only from
remote machines that send a correct machine password in F Code. Enter up to 20
digits using the screen keyboard on the touch screen. Permissible characters are 0 to
9, *, #, and <space>. When using this feature, you cannot receive documents from
remote machines without the F Code function.
G3 Line 1
•Fax ID
Specifies the G3 ID (fax number). Enter up to 20 digits, comprising 0-9, +, and
<space> characters.
• Dial Type
Specifies tone or pulse dialing.
•Line Type
Specifies subscriber line (PSTN) or private branch exchange (PBX) line type.
Internet Fax Control
This feature allows you to define Internet Fax control functions.
1. Select [Internet Fax Control] in
the [Features] menu.
2. Change the required settings.
Use the scroll buttons to switch
between screens.
3. Select [Close].
Internet Fax Path
Specifies the Internet Fax path. Select [Via E-mail Server] to send through a mail
server. Select [Direct (P2P)] to bypass the SMTP server and send directly to an Internet
Fax-capable machine.
Broadcast Internet Fax Profile
Specifies the default Internet Fax profile for broadcasting.
For more information on Internet Fax profile, refer to
Internet Fax Profile on page 111 .
NOTE: Although [TIFF-S] can be received by any remote machine supporting Internet
Fax, [TIFF-F] and [TIFF-J] may not be received. When you set to [TIFF-F] or [TIFF-J],
check the capability of the remote machine in advance.
Broadcast Starting Rate
Specifies the default starting rate for broadcasting Internet Fax.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
