Xerox WorkCentre 5230A User Manual

Server Fax Installation
303
4. Configure the fax server, referring to the fax management software
manufacturer’s documentation, so that it is able to monitor the fax repository for
incoming documents.
NOTE: Follow the fax server software manufacturer’s instructions for any other
settings required to use the Fax Server service.
Machine Configuration
1. Set TCP/IP and HTTP for the machine. This is required to access CentreWare
Internet Services, which can be used to configure Server Fax settings from a
networked computer. For details on how to set TCP/IP and HTTP, refer to
CentreWare Internet Services Installation on page 150 .
2. Enable the port to be used for the Server Fax service. The transfer protocols
available for the Server Fax service are FTP, SMB, and SMTP. For details on how
to enable a port, refer to
Port Settings on page 90 .
NOTE: To verify that TCP/IP and HTTP are correctly configured and the port is
enabled, you can print a Configuration Report. For information on the Configuration
Report, refer to
Machine Status on page 49 .
3. Follow the steps below to enable the Server Fax service, to set the fax repository
(the directory on the Server Fax server to store transferred images), and then to
set the protocol.
1) Start a web browser on a computer.
2) In the URL field, enter “http://” followed by the Internet address of the machine.
Then press the <Enter> key on the keyboard.
NOTE: If you use the IP address to specify the machine, use one of the following
formats depending on your machine configuration. The IPv6 format is supported on
Windows Vista only. An IPv6 address needs to be enclosed in square brackets.
(For IPv4) http://xxx.xxx.xxx.xxx
(For IPv6) http://[xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx]
NOTE: If you have changed the port number from the default port number “80”,
append the number to the Internet address as follows. In the following examples, the
port number is 8080.
(For IPv4) http://xxx.xxx.xxx.xxx:8080
(For IPv6) http://[xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx]:8080
The following describes how to enable the Server Fax service. If the Fax service is not
installed on the machine, skip steps 3) to 7) and proceed to step 8).
3) In CentreWare Internet Services, click the [Properties] tab.
4) Expand the [Services] folder, and then expand the [Fax] folder.
5) Click [Fax Settings], and then under [Fax Service], select [Scan to Fax Server].
6) Click the [Apply] button.
7) On the right frame of the screen, click [Reboot Machine] to reflect the setting.
The following describes how to configure the repository settings. The repository
settings can only be configured using CentreWare Internet Services.
8) In CentreWare Internet Services, click the [Properties] tab.
9) Expand the [Services] folder, and then expand the [Fax] folder.
10)Click [Defaults].

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
