Network-related Problems
389
– RFC2617: HTTP Authentication: Basic and Digest Access Authentication
(Basic authentication support only, others are not supported)
– RFC2817: Upgrading to TLS Within HTTP/1.1
– RFC2818: HTTP Over TLS
• HTTP/HTTPS scheme compatibility, GET/CONNECT/HOST method compatibility
IPv6 Addresses
Restrictions
This section explains the restrictions on network connection using an IPv6 address.
CentreWare Internet Services
• When SSL is enabled, “http://[IPv6 address]” entered on a web browser is not
redirected to “https://[IPv6 address]”. Directly specify “https://[IPv6 address]”.
Printing
• The following operating systems support IPv6 printing.
– Windows Vista
– Mac OS except Mac OS X 10.4 and earlier
– Linux distributions with CUPS that supports IPv6
• The WINS protocol does not support IPv6 communication.
• On an IPv6 network without a DNS server, the machine cannot be connected to
Windows Vista via SMB.
• NetWare does not support IPv6 communication. Use IPv4 for NetWare.
• Bonjour does not support IPv6 communication. Use IPv4 for Bonjour.
Scanning
• When IPv6 is enabled and IPv4 is disabled on the machine, the Browse function of
the Scan to PC (SMB) service is not available.
• In an IPv6 network with no DNS server installed, the file transfer using the Scan to
PC service fails if a destination server is specified using the computer name. Directly
specify the IPv6 address.
Discovery
• IPv6 devices cannot be searched in UPnP. Use the WSD discovery function for IPv6
device search.
Authentication
• In an IPv6 network without a DNS server, SMB authentication fails if an SMB server
is specified using the computer name. Directly specify the IPv6 address.
Connection to External Applications (Custom Services)
• External applications, such as DocuShare, cannot be specified in IPv6 address
format. The machine supports only the domain name format or the IPv4 format to
access external applications. In IPv6 environment, use a DNS server and specify
applications in domain name format.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
