Xerox WorkCentre 5230A User Manual

15 Problem Solving
390
Fault Codes
When a fault occurs, the touch screen displays a message on how to clear the fault.
Some faults indicate customer maintenance, while others require the attention of the
System Administrator. The following table represents some of the fault codes and their
corresponding corrective actions. These may appear in the Print Queue or Faults List
available in the Machine Status mode.
Code Description and Remedy
002-500 An error occurred during the scan processing. Try scanning again, or check the
restrictions on Xerox Standard Accounting. Contact the Xerox Welcome Center
if the problem persists.
002-770 The job template could not be processed due to insufficient hard disk space.
Delete unnecessary data from the hard disk.
003-750 No document was saved for the double-sided Booklet Creation feature. Check
the setting of the double-sided Booklet Creation feature.
003-751 The specified document area is too small. Select a higher resolution or a larger
scan area.
003-752 The selected resolution was too high for scanning mixed size documents using
the document feeder. Specify less than 600 dpi for the resolution setting and
scan again.
003-753 The selected resolution was too high for scanning mixed size documents using
the document feeder. Specify 200 dpi for the resolution setting and scan again.
003-754
003-755
An error occurred in the document scanner. Reset the document, and scan
again.
003-756 The document pages are blank. Correctly load the document.
003-757 The scan job could not be processed with the specified resolution due to
insufficient memory. Specify less than 400 dpi for the resolution setting.
003-760 Incompatible scan options are selected. Check the selected options.
003-761 The paper size in the tray selected by auto tray switching, differs from the paper
size in the tray selected at the tray selection. Either change the paper size for
the tray, or change the paper type priority setting.
003-764 The machine cannot perform [Form Overlay] since the scanned document
contains one page only. Make sure that the document contains at least two
pages: a page with a form image (which must be the first page of the document)
and a page that the form image will overlay.
003-780 Compression of scanned data was unsuccessful. Lower the resolution or
reduction/enlargement ratio to reduce the data size, or divide the document in
smaller segments.
003-795 The reduction/enlargement ratio exceeds the setting range when the scanned
document is enlarged/reduced to the specified paper size. Directly enter the
reduction/enlargement ratio, or change the paper size.
003-981 Stapling mixed size documents is available only for documents with the same
width. Cancel the staple feature or set the documents with the same width.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
