Xerox WorkCentre 5230A User Manual

Job Flow Service Setup
293
Procedure for Scan to PC Setup (SMB)
1. On the control panel, select [Scan to PC].
2. Enter all the information required. See the User Guide for more detailed
information.
3. Load a sample document into the document feeder.
4. Press the <Start> button on the machine.
5. Log on to the SMB server. Navigate to the directory path (repository) that was set
up earlier on the server. Your scanned document can be found in the specified
directory.
NOTE: If Remote Authentication has been enabled, a separate login screen appears
when the Scan to PC (SMB) service is selected. Documents are not scanned unless
the authentication server authenticates user access.
Job Flow Service Setup
To use the Job Flow service, you need to enable the SOAP port, the SNMP port, and
the Internet Services (HTTP) port, and then to set the IP address. The procedure for
configuring the machine is as follows.
NOTE: The configuration can also be performed using CentreWare Internet Services.
For details, refer to
CentreWare Internet Services on page 149 .
1. Enter the System Administration mode, and press the <Machine Status> button
on the control panel and then select the [Tools] tab on the touch screen.
NOTE: For details on how to enter the System Administration mode, refer to
Setting
Procedure on page 63
.
2. Enable the SOAP port.
Server Shared Name Required This is the name assigned to the shared
folder on the SMB server.
Repository – directory path, where
the document will be stored on the
SMB server
Required This is the location or path of the directory for
saving scanned documents.
SMB Login/password information Optional This is required if the SMB server requires
login/password authentication. Most SMB
servers require a login/password.
Remote Authentication Server’s IP
Address
Optional If Remote Authentication is required, then the
Authentication feature needs to be enabled.
Data to Set Up Scan to PC
(SMB)
Install
Requirement
Comments

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
