Xerox WorkCentre 5230A User Manual

13 Security - Encryption/Digital Signature
306
Encryption of HTTP Communications from the Machine to a Remote Server (Client
Certificate)
The SSL/TLS suite of protocols is used to encrypt HTTP communications with a remote
server.
No client certificate is typically required for this activity. However, if a remote server is
set to require an SSL client certificate, an SSL/TLS client certificate must be registered
on the machine.
Digital certificates imported from a Certificate Authority can be used as SSL/TLS
certificates on the machine’s HTTP server.
NOTE: When Remote Server Certificate Validation is enabled, under [SSL/TLS
Settings] in CentreWare Internet Services, the root certificate of the remote server
must be registered to the machine (imported with Internet Services) to verify the digital
certificate.
E-mail Encryption/Digital Signature
S/MIME certificates, imported from a Certificate Authority (in PKCS7 format), can be
used on the machine’s HTTP server for e-mail encryption.
To import S/MIME certificates, use [Machine Digital Certificate Management] in the
[Security] folder on the [Properties] page of CentreWare Internet Services.
Encryption/Digital Signature of Scanned Files (PDF/XPS Documents)
While no digital signatures are required to encrypt PDF and XPS documents, these
documents can be signed with imported PKCS12 digital signatures.
When digital signatures are added to PDF or XPS documents, scan file certificates
imported to the machine from a Certificate Authority are typically used.
To import PKCS12 scan file certificates, use [Machine Digital Certificate Management]
in the [Security] folder on the [Properties] page of CentreWare Internet Services.
IPsec
IPsec (typically used to encrypt FTP) can be enabled from the [Security] folder on the
[Properties] page of CentreWare Internet Services.
Configuration of HTTPS (SSL/TLS) Communication Encryption
Installation Overview
Configuration on the Machine
Two methods are available depending on the type of certificate.
- Create a self-signed certificate on the machine with CentreWare Internet Services,
and enable HTTPS. This method is used primarily for server certificates.
- Enable HTTPS, and import a signed certificate from a Certificate Authority using
[Machine Digital Certificate Management] in the [Security] folder on the [Properties]
page of CentreWare Internet Services.
NOTE: To see [Certificate Management], at least one certificate must have been
created and stored on the machine. This is one of the reasons for creating a self-
signed certificate.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
