Xerox WorkCentre 5230A User Manual

305
13 Security - Encryption/Digital Signature
This chapter describes how to configure the encryption and digital signature features
for the machine.
The following information is provided:
Types of Encryption/Digital Signature Services Available – page 305
Configuration of HTTPS (SSL/TLS) Communication Encryption – page 306
Configuration of E-mail Encryption/Digital Signature – page 308
Configuration of Scan File Signatures (PDF/XPS Documents) – page 311
Configuration of IPsec – page 313
NOTE: Some of the features described in this chapter are optional, and may not apply
to your machine configuration.
Types of Encryption/Digital Signature Services Available
The communication data between the machine and computers on a network can be
encrypted.
Encryption for the machine, as described in this chapter, is set up using CentreWare
Internet Services.
NOTE: For details on CentreWare Internet Services, refer to
CentreWare Internet
Services on page 149
.
The quickest and easiest, although not the most reliable, method to use to set up initial
HTTP communication encryption is the generation of a self-signed certificate (as stated
under
Configuration of HTTPS (SSL/TLS) Communication Encryption on page 306 ).
To manage digital certificates stored in the machine, click [Machine Digital Certificate
Management] in the [Security] folder on the [Properties] page of CentreWare Internet
Services.
Encryption of HTTP Communications from a Client to the Machine (Server Certificate)
The SOAP port, Internet service (HTTP) port, IPP port, and WebDAV port use the
HTTP server of the machine.
The SSL/TLS suite of protocols is used in the encryption of HTTP communications from
a client to the machine. A user of a client computer accesses the machine’s HTTP
server by typing “https://”, followed by the Internet address of the machine, into the
[Address] box of a web browser application. The machine then offers the client a Digital
Certificate, which the client accepts (after reviewing the validity of same). Upon
acceptance of the Digital Certificate, a Public Key exchange takes place, encryption
algorithms are agreed upon between the two parties, and the client uses the server’s
Public Key to communicate with the server using digitally signed and encrypted data.
Digital certificates imported from a Certificate Authority, or self-signed certificates
created with CentreWare Internet Services, can be used as SSL/TLS certificates on the
machine’s HTTP server.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
