Xerox WorkCentre 5230A User Manual

TCP/IP (LPD or Port9100)
263
Computer Setup
Install the print driver on the client computer. Refer to the HTML document on the PCL
Print Driver CD-ROM.
Test Print
Make sure the machine has been installed on the network correctly by submitting a test
print from each client computer. Perform the following steps.
1. Open a document on a client computer.
2. Select the machine as the printer.
3. Print the document on the machine and verify that it prints correctly.
4. Make sure that the print driver is installed on every computer that will be sending
jobs to the machine.
5. Repeat the test for all computers that will be sending jobs to the machine.
The installation process is now complete.
If the test print fails, refer to
Problem Solving on page 349 .
TCP/IP (LPD or Port9100)
This section explains how to set up the machine to print from a Windows computer
through LPD or Port9100. The following information is provided:
Information Checklist – page 263
TCP/IP (LPD or Port9100) Environments – page 264
TCP/IP (LPD or Port9100) Installation – page 264
Installation Procedure – page 264
Network Communication Setup – page 265
Computer Setup – page 265
Test Print – page 265
Information Checklist
Before starting these procedures, make sure that the following items are available or
have been performed.
Item By
An existing operational network utilizing TCP/IP is required. These
procedures are not designed to install a network.
Customer
Obtain and record the following information:
• IP address
• Gateway address
• Subnet mask (for IPv4) / Prefix (for IPv6)
• Host name
Customer
Test the machine to make sure that it is fully installed and functioning
correctly.
Customer
Install the print driver. Customer

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
