Xerox WorkCentre 5230A User Manual

Scan to Home Setup
289
For more details about each protocol settings, refer to the following section:
FTP:
Scan to PC Setup (FTP) on page 291 .
SMB:
Scan to PC Setup (SMB) on page 292 .
HTTP/HTTPS:
HTTP on page 198 . For HTTPS, also refer to Configuration of
HTTPS (SSL/TLS) Communication Encryption on page 306
.
NetWare:
NetWare on page 188 .
4. A repository (folder) needs to be created on the server to hold scanned
documents.
Procedure for Network Scanning Setup
1. Create templates and repositories via CentreWare Internet Services.
2. On the control panel, select [Network Scanning].
3. Select a template from the list. You can change any other value from the control
panel without impacting the template configuration; only the current job will be
affected.
4. Load a sample document into the document feeder.
5. Press the <Start> button on the machine. The job is sent to the server using the
protocol as defined within the template.
6. Log on to the server. Navigate to the repository (folder) that was specified earlier.
Your scanned document is located in that repository.
NOTE: If the authentication feature is enabled for the Network Scanning service, a
separate login screen appears when [Network Scanning] is selected on the All
Services screen. Users can use the service after authenticated.
Computer Setup
For more information about programming templates using CentreWare Internet
Services, refer to
CentreWare Internet Services on page 149 .
Scan to Home Setup
The Scan to Home feature is supported through the Network Scanning service.
Essentially, it is a template file (.xst) stored locally on the machine, but in a different
directory than the Network Scanning templates or mailbox folders.
Data to Set Up Network Scanning
Install
Requirement
Comments
Templates are created via CentreWare
Internet Services or any other Xerox
Network Scanning Solutions.
Required Refer to Job Templates on page 162 .
Repositories are created via CentreWare
Internet Services or any other Xerox
Network Scanning Solutions.
Required Refer to
Network Scanning on page 209 .
Remote Authentication Server’s IP Address Optional If Remote Authentication is required,
then the Authentication feature needs to
be enabled.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
