Xerox WorkCentre 5230A User Manual

8 Printer Environment Settings
264
If problems are encountered during machine setup, refer to Problem Solving on
page 349
.
TCP/IP (LPD or Port9100) Environments
System configuration
As the machine supports the LPD and Port9100 protocol, you can print directly from a
Windows computer.
When printing from Windows NT4.0/Windows 2000/Windows XP/Windows Server
2003/Windows Vista computers through the LPD port, use the OS standard LPR port.
When printing through Port9100, change the necessary settings on the computers.
The transport protocol for LPD and Port9100 can be TCP/IP.
You will also need to set up the IP address on the machine and the Windows
computers.
NOTE: Windows NT 4.0 does not support printing through Port9100.
Target computers
The following computers support printing through LPD or Port9100.
NOTE: The optional PostScript Kit is required when you print from a Macintosh.
TCP/IP (LPD or Port9100) Installation
This section describes how to set up the machine to use the LPD and Port9100
protocols.
Installation Procedure
There are three stages to enable printing on the machine through LPD or Port9100.
Network Communication Setup
Enable the following ports using the touch screen or CentreWare Internet Services.
• Printing through LPD: LPD port
• Printing through Port9100: Port9100 port
Set the IP address using the touch screen.
Connection OS Protocol
LPD port Windows NT 4.0
Windows 2000
Windows XP
Windows Server 2003
Windows Vista
TCP/IP
Port9100 Windows 2000
Windows XP
Windows Server 2003
Windows Vista
TCP/IP

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
