Xerox WorkCentre 5230A User Manual

Overview of Authentication
317
NOTE: A registered user ID on the remote authentication server can be a maximum of
32 characters, and the passcode a maximum of 128 characters. For SMB
authentication, the passcode can be a maximum of 32 characters.
Xerox Secure Access
A system such as the magnetic-card, IC-card, or biometrics system is used for
authentication. If prompted, users need to enter their user information on the machine’s
control panel.
For accounting purposes, Xerox Secure Access can work with Network Accounting.
Functions Controlled by Authentication
The following explains the functions that are restricted by the Authentication feature.
Restriction depends on which of the following two ways the machine is used.
• Local Access
• Remote Access
For more information on the restrictions to mailboxes and job flow sheets using the
Authentication feature, refer to
Authentication for Job Flow Sheets and Mailboxes on
page 318
.
Local Access
Direct operation of the machine from the control panel is called Local Access.
The functions restricted by Local Access are as follows.
Device Access
• All Services Pathway - verifies users when they access a service screen.
• Job Status Pathway - verifies users when they access the Job Status screen.
• Machine Status Pathway - verifies users when they access the Machine Status
screen.
Service Access
•Copy
•Fax
• Internet Fax
• Scan to Mailbox
•E-mail
• Network Scanning
• Scan to PC
• Send from Mailbox
• Stored Programming
• Job Flow Sheets
•Custom Services

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
