Configuration of HTTPS (SSL/TLS) Communication Encryption
307
NOTE: The [Certificate Management] folder does not appear under the [Security]
folder until you enable [HTTPS - SSL/TLS Communication] in [SSL/TLS Settings].
Configuration on a Computer
Use Internet addresses beginning with "https" in web browser applications.
Configuring Certificates with CentreWare Internet Services
Configuration on the Machine
Two methods are available to configure certificates with CentreWare Internet Services:
creating a self-signed certificate (for SSL server), and importing a signed certificate
from a Certificate Authority.
This section describes how to create a self-signed certificate (for SSL server).
NOTE: When SSL communication is performed using a self-signed certificate created
on the machine, or using a certificate with which the character code is indicated by
UTF-8, the following occur:
• If Internet Explorer is used with Windows 98SE or earlier, the issuer/issuing place of
the certificate will not be displayed correctly.
• SSL connection will not be made if Internet Explorer is used with Mac OS X 10.2 or
later.
This is because the operating system cannot recognize the character code (UTF-8)
of the certificate. Use Netscape 7 in the above-mentioned OS environments.
For information on importing certificates with CentreWare Internet Services, refer to
Properties in the CentreWare Internet Services chapter on page 178.
NOTE: When a certificate is to be imported, if the same certificate has been already
registered in [Local Device] or [Others], the certificate cannot be imported. Delete the
registered certificate before importing.
1. Start a web browser.
2. Enter the machine’s Internet address (beginning with “https”) into the Address box
of your web browser, and press the <Enter> key.
Example: https://192.168.1.1/
3. Click the [Properties] tab.
4. Click [+] on the [Security] folder to display the items in the folder.
5. Click on [Machine Digital Certificate Management].
6. Generate a certificate.
a. Click the [Create Self-Signed Certificate] button.
b. Set [Public Key Size] as necessary.
c. Set [Issuer] as necessary.
d. Click the [Apply] button. When a screen to enter the user ID and passcode
appears, enter the System Administrator user ID and passcode, and then click
[OK].
NOTE: The default System Administrator user ID and passcode are "11111" and "x-
admin" respectively.
7. Refresh the web browser.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
