Xerox WorkCentre 5230A User Manual

Remote Authentication Setup
341
6. Click [Apply] to reboot the machine.
7. Expand the [Security] folder, and then click [Authentication Configuration]. On the
page displayed, place a checkmark in the [Enabled] box for each service that you
wish to restrict access to.
NOTE: If the [Guest User] box is available and configurable, consider whether it is
advisable in your network environment to allow simple passcode, guest access to this
restricted service machine. The default setting is [Off].
8. Click [Next].
9. Click [Configure] for [Authentication System].
10. Select your system from the [Authentication System Settings] drop-down list.
Configure the [Server Response Time-Out] and [Search Time-Out] settings. Click
[Apply].
11. For further configuration, refer to one of the following sections depending on the
system selected in [Authentication System Settings] in step 10:
Configuring Remote Authentication for Kerberos (Windows 2000) – page 341
Configuring Remote Authentication for Kerberos (Solaris) – page 341
Configuring Remote Authentication for SMB – page 342
Configuring Remote Authentication for LDAP – page 342
Configuring Remote Authentication for Kerberos (Windows 2000)
At your Workstation:
1. Click the [Properties] tab.
2. Expand the [Security] folder, and then the [Remote Authentication Servers] folder.
3. Click [Kerberos Server].
4. Under [Kerberos Server 1 (Default)], enter the IP address and port of the primary
server (domain controller running the key distribution center service).
5. Enter the IP address and port of the secondary server (domain controller), if
necessary.
6. Enter the Windows 2000 domain in the [Domain Name] box. For example (in
uppercase): EXAMPLE.COM
7. Enter details for up to four alternate domain controllers and backups, if required.
8. Click [Apply].
Configuring Remote Authentication for Kerberos (Solaris)
At Your Workstation:
1. Click the [Properties] tab.
2. Expand the [Security] folder, and then the [Remote Authentication Servers] folder.
3. Click [Kerberos Server].
4. Under [Kerberos Server 1 (Default)], enter the IP address and port of the primary
server (the server running the key distribution center service).
5. Enter the IP address and port of the secondary server, if necessary.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
