Xerox WorkCentre 5230A User Manual

15 Problem Solving
388
When you cannot connect to a web server
Restrictions
This section explains the restrictions that apply while using Internet or intranet
connections.
Internet/Intranet connections
Connection to the Internet or an intranet depends on various settings, including the
destination web server, the used server application, proxy server, and firewall types.
When connecting to the Internet or an intranet using server application software, proxy,
or firewall supplied by another company, the following conditions are required.
• Windows 2000, Windows XP, Windows Server 2003 or Windows Vista operating
system
• Conformance with the following conditions:
– RFC2616: Hypertext Transfer Protocol HTTP/1.1
(Normal connections, SSL connections, Proxy authentication)
An error occurred, but no
message is displayed on the
control panel.
No message is displayed on the control panel even when an
error occurs during execution of background processes.
Display the [Job Status] screen or print a job history report
and check the results.
Cannot connect due to proxy
server, firewall, or web server
access restrictions.
Check if any of the following access restrictions are set.
• Address (port) restrictions
• SSL usage restrictions
• User access restrictions (including access privileges)
• Content blocking
• Scheme restrictions (for example, HTTP disable)
• Transfer data size restrictions
• Used method restrictions (for example, POST disable)
• HTTP header restrictions (for example, specific browsers)
• Time restrictions (for example, time-limited access)
A certificate is not registered
for using the iFlow service.
The iFlow service cannot be used without certificate
authentication. Obtain a certificate for the required machine
and register the certificate on the machine.
Problem Action
The settings are not for using
the proxy server.
In a proxy environment, the web server cannot be connected
without the proxy server settings. Enter the settings for using
the proxy server.
The settings are for using a
proxy server in a non-proxy
environment.
For environments where connecting via a proxy is not
required, such as connecting to an intranet, the settings
should not be set for using a proxy server.
The proxy server address is
not set correctly.
When setting up a proxy server, the web server cannot be
connected if the proxy server address is not set correctly.
Enter the correct proxy server address.
The user name and/or
password are entered
incorrectly when proxy server
authentication is set.
Register the user name and password on the machine to
grant connection access to the proxy server.
Problem Action

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
