Xerox WorkCentre 5230A User Manual

7 CentreWare Internet Services
164
File File
Destination
Displays the defined scan file repository.
Edit Displays a page where you can set a new scan file
repository or edit an existing repository.
Filing Policy
Specify the filing policy for saving a new file when a file of
the same name already exists in the file repository.
• Rename New File – Adds a three-digit number from
001 to 999 to the name of the new file. File names
increment sequentially when additional documents of
the same name are scanned.
• Append to Existing File – Adds a newly scanned file to
the existing file.
• Overwrite Existing File – Overwrites the previously
scanned file with the new file.
• Do not Save – Does not save the new file if a file with
the same name already exists.
• Add Date to Name – Adds the current date to the name
of the new file.
File Destination
Select the desired file repository from the list of file
repositories set in [Properties] > [Network Scanning] >
[File Repository Setup].
Protocol
Displays the filing protocol set in [Properties] > [Network
Scanning] > [File Repository Setup].
Host Name/IP Address & Port
Displays the host name/IP address and port number of
the filing protocol set in [Properties] > [Network Scanning]
> [File Repository Setup].
Document Path
Displays the path to the file repository set in [Properties]
> [Network Scanning] > [File Repository Setup].
Login Name
Displays the login name set in [Properties] > [Network
Scanning] > [File Repository Setup].
Document
Management
Fields
(Optional)
Field Name,
Field Label,
Default Value
Displays the meta data attributes for the job template.
This setting is optional.
Add Displays the [Add Document Management Field] page
where you can add field names, labels, and default
values, and specify whether the fields are editable or not.
Edit Select an existing field and click this button to make
changes to the field.
Delete Select an existing field and click this button to delete the
field.
Feature Description

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
