Page #183 background image
Properties
183
General Setup Memory
Settings
(continued)
LPD
Allows you to select the spool destination for the job.
Spool to Memory – Enter a value between 512 KB
and 32 MB (32768 KB) in 256 KB increments.
Spool to Hard Disk – The print page buffer text box
will be blank and the value cannot be updated.
No Spooling – Enter a value between 1024KB and
2048KB in 32 KB increments.
IPP
Allows you to select the spool destination for the job.
Spool to Hard Disk – The print page buffer text box
will be blank and the value cannot be updated.
No Spooling – Enter a value between 64 KB and
1024 KB in 32 KB increments.
Port 9100
Enter the print page buffer for the Port9100 interface
between 64 KB and 1024 KB in 32 KB increments.
PostScript Memory
Enter the PostScript working memory between 16384
KB and 98304 KB in 256 KB increments.
Job Ticket Memory
Enter the job ticket working memory between 256 KB
and 8192 KB in 256 KB increments.
Internet
Services
Settings
Allows you to configure the settings for CentreWare
Internet Services.
Auto Refresh Interval
Enter a time in seconds when the contents of the
browser display will be refreshed automatically.
Pool Server
Settings
Allows you to set the pool server related information for
job flow services.
Pool Server
Select to enable the pool server.
Login Details from Device
Select whether or not to use the login details defined
by the machine.
User Name
Enter the user name to be used when accessing the
pool server with up to 64 characters.
Password
Enter the password for the user name with up to 32
characters.
Feature Setting items

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox WorkCentre 5230A and is the answer not in the manual?

Xerox WorkCentre 5230A Specifications

General IconGeneral
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Economical printingYes
Time to first page (black, normal)4.3 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Power supply typeAC
Dimensions (WxDxH)640 x 652 x 1113 mm
Power requirements220 – 240V, 50/60 Hz
Printer managementSNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking featuresFast Ethernet
All-in-one functionsCopy, Scan
Standard media sizes89 x 98.4mm - 297 x 420mm
Maximum internal memory0.768 GB
Color all-in-one functionsscan, n
Compatible operating systemsWindows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)72/38 dB
Scanner typeFlatbed scanner
Input color depth24 bit
Maximum scan area297 x 432 mm
Image formats supportedJPG, TIF
Copier resize25 - 400 %
Maximum copy resolution600 x 600 DPI
Maximum number of copies999 copies
Copy speed (black, normal quality, A4)30 cpm
Total input capacity1100 sheets
Total output capacity500 sheets
Maximum input capacity5100 sheets
Auto document feeder (ADF) input capacity75 sheets
Internal memory512 MB
Processor familyPowerPC
Internal storage capacity40 GB
Sound pressure level (printing)22 dB
Display-
Market positioningBusiness
Envelopes sizesC5, DL
Maximum print size297 x 420 mm
Media weight (tray 1)60 to 105 g/sm2
Paper tray media typesBond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizesLegal
ISO A-series sizes (A0...A9)A3, A4, A5
ISO B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA3
Multi-Purpose Tray media weight60 - 215 g/m²
Supported network protocols (IPv4)TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfacesUSB 2.0
Power consumption (standby)95 W
Power consumption (average operating)615 W
Sustainability certificatesENERGY STAR
Maximum duty cycle100000 pages per month
Recommended duty cycle12000 pages per month
Operating temperature (T-T)10 - 28 °C
Operating relative humidity (H-H)15 - 85 %
