Xerox WorkCentre 5230A User Manual

Overview of Account Administration
333
*1: If [Print Service] on the [Auditron Mode] screen is set to [Disable Accounting] in the
System Administration mode, no authentication is required to access mailboxes
shared by the System Administrator, and the machine will print the job as
unauthenticated.
When using the Account Administration feature for fax jobs, note the following:
• Sending documents from different user accounts to the same destination will not be
counted as combined sending.
• The communication rate is calculated using the machine’s built-in timer.
Accordingly, the fees calculated may be slightly different from those calculated by
the telephone company.
• When you receive faxes divided into pages, the machine counts the page numbers
received instead of the page numbers printed.
• Fax jobs are not counted in the following cases:
– When dialing a fax number using the numeric keypad on the control panel or the
On-hook feature.
– When using a speed dial code in which the billing information is not registered.
– When a phone conversation took place, including the one before a transmission.
Scan
The items you can manage for scan jobs using the Account Administration feature are
as follows:
Internet
Fax
Receive/
Print
Printing received
documents
automatically
No Incoming
Internet Fax
Receptions/pages,
printed pages/sheets
Automatic
confidential
receiving
No Incoming
Internet Fax
Receptions/pages
Printing confidential
documents
Yes
*1
Verified Printed pages/sheets
Forward
Internet
Fax
Documents
Receiving relayed
Internet Fax
documents
No Incoming
Internet Fax
Receptions/pages
Automatic fax
forwarding
No Incoming
Internet Fax,
forwarded faxes
Sent faxes/pages,
transmissions
Services
Account
Information
Required
User Type Manageable Items
E-mail Yes Verified Scanned pages, sent pages
Scan to Mailbox Yes Verified Scanned pages, stored
pages
Jobs
Account
Information
Required
User/
Document
Type
Manageable Items

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
