Paper Jams

351

Tray 6

(High Capacity

Feeder)

Top Cover

Tray 6

(High Capacity

Feeder)

Front Cover

Office Finisher LX

Transport Cover F

Office Finisher LX

Front Cover

Tray 3

Tray 4

(High Capacity

Tandem Tray)

Office Finisher LX

Top Cover
