15 Problem Solving
358
2. Hold the handle on the top left of
Tray 6, and move Tray 6 to the
left of the machine.
3. Remove the jammed paper.
4. Gently put Tray 6 back into
position.
Under the Top Cover of Tray 6
1. Open the top cover of Tray 6.
2. Remove the jammed paper.
3. Close the top cover.
In Tray 6
1. Pull out Tray 6.
2. Remove the jammed paper.
3. Close Tray 6.
