Network-related Problems
371
When the machine or other SMB machines are not found from client computers
When printing fails
When the document cannot be deleted from the printer window
The host name specified for
the machine is already
defined for a different
machine.
Check if the host name is
duplicated in the SMB status
information of the System
Settings List.
Use CentreWare Internet
Services to change the host
name to a different name, or
reset the machine settings to
the initial values.
The function to search for
computer names is not
available in IPv6
environment.
Check if Windows Vista
displays the machine in a list
of networked computers.
Edit the file “hosts” saved in
“C:\Windows\system32\driver
\etc” to associate the host
name with the IPv6 address,
and then type “\\host name”
in the Address bar on
Explorer.
Cause Confirmation Method Action
If the SMB [Auto Master
Mode] is [On], there are limits
to the number of machines
that can retain the machine
information. The number
varies with the network
environment.
The machine or other SMB
machines cannot be found
using the network computer
icon.
Check the SMB [Auto Master
Mode] setting. If set to [On],
change the setting to [Off].
Cause Confirmation Method Action
The machine is processing a
print request from another
client. (The receiving buffer is
set to non-spool mode.)
Check that the machine has
a print job in progress. (This
indicates whether there are
files ready to print, and
displays any write error
dialogs.)
After the machine has
processed the print request,
send a print job or change the
mode to the spool mode.
The number of sessions
exceeds the maximum.
Check that the machine is
processing simultaneous
requests (such as a print
request or status inquiry
request) from multiple clients.
(This indicates remote clients
unable to use the machine,
and displays any write error
dialogs.)
Wait for a while, and send a
print request again.
Cause Confirmation Method Action
An attempt is made to delete
all documents displayed in
the printer window.
(System Administrator only)
Check whether the attempt
has been made to delete the
print job from the Printer
menu in the printer window.
Delete the print job from the
Document menu in the printer
window.
Cause Confirmation Method Action

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
