Xerox WorkCentre 5230A User Manual

Fault Codes
393
016-454 Unable to retrieve the IP address from DNS. Check the DNS configuration and
IP address retrieve setting.
016-455 Connection to the SNTP server was timed out. Check the network cable
connection and the IP address of the SNTP server.
016-456 Received a message from the SNTP server saying that it was not synchronized
with the standard time source. Check the SNTP server settings.
016-500
016-501
016-502
An error occurred during data write processing. Contact the Xerox Welcome
Center.
016-503 Unable to resolve the name of the SMTP server when e-mail was transmitted.
Check if the SMTP server is set correctly using CentreWare Internet Services.
Also, check that the DNS server is set correctly.
016-504 Unable to resolve the name of the POP3 server when e-mail was transmitted.
Check if the POP3 server is set correctly using CentreWare Internet Services.
Also, check that the DNS server is set correctly.
016-505 Unable to log in to the POP3 server when transmitting e-mail. Check if the user
name and password used for the POP3 server are set correctly using
CentreWare Internet Services.
016-513 An SMTP server connection timeout error occurred. The SMTP server or
network is overloaded. Wait for a while, and try again.
016-514 An XPS error occurred. Use a print driver on XPS Viewer to submit a print job.
016-515 The memory space for XPS data is not sufficient. Change the print mode to a
higher processing mode. If the problem persists, add memory. If the problem still
persists, use a print driver on XPS Viewer to submit a print job.
016-516 An XPS print ticket error occurred. Check if you used the correct print steps on
your application. If the problem persists, contact the application vender.
016-518 A PostScript error occurred. Disable either the booklet-creation or Watermark
feature.
016-519 The print volume reached the limit. If necessary, change the limit of print
volume.
016-522 An LDAP server SSL authentication error occurred. An SSL client certificate
could not be acquired. The LDAP server requires an SSL client certificate. Set
the SSL client certificate on the machine.
016-523 An LDAP server SSL authentication error occurred. The LDAP server’s SSL
certificate is not trusted. Register the root certificate of the LDAP server SSL
certificate on the machine.
016-524 An LDAP server SSL authentication error occurred. The server certificate will
expire soon. Change to a valid LDAP server SSL certificate, or set [LDAP -
SSL/TLS Communication] under [SSL/TLS Settings] to [Disabled] to avoid the
error.
016-525 An LDAP server SSL authentication error occurred. The server certificate has
expired. Change to a valid LDAP server SSL certificate, or set [LDAP - SSL/TLS
Communication] under [SSL/TLS Settings] to [Disabled] to avoid the error.
Code Description and Remedy

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
