Xerox WorkCentre PE220 User Manual

10 Specifications
Xerox PE220 10-11
Be sure the seam extends all the way to the corner of the envelope as
illustrated below.
Envelopes with Adhesive Strips or Flaps
Envelopes with a peel-off adhesive strip or with more than one flap that folds
over to seal must use adhesives compatible with the heat and pressure in the
machine. The extra flaps and strips might cause wrinkling, creasing or even
jams and may even damage the fuser.
Envelope Margins
The following gives typical address margins for a commercial #10 or DL
envelope.
NOTE:
• For the best print quality, position margins no closer than 0.6 in. (15 mm)
from the edges of the envelope.
• Avoid printing over the area where the envelope’s seams meet.
Envelope Storage
Proper storage of envelopes helps contribute to print quality. Envelopes
should be stored flat. If air is trapped in an envelope, creating an air bubble,
then the envelope may wrinkle during printing.
Labels
CAUTION:
– To avoid damaging the machine, use only labels recommended for
laser printers.
Type of Address Minimum Maximum
Return address 0.6 in. (15 mm) 2 in. (51 mm)
Delivery address 2 in. (51 mm) 3.5 in. (90 mm)
Correct
Incorrect

Xerox WorkCentre PE220 Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan, Fax
Grayscale Depth	8-bit
Standard Media Capacity	250 sheets
PC Connection	USB 2.0
Scan Resolution	600 x 600 dpi
Color Depth	24-bit
Media Size Class	A4
Max Media Size	8.5 x 14 inches
Supported Media Type	Envelopes, Transparencies, plain paper
Supported Operating Systems	Windows, Mac OS
Print Speed	Up to 22 ppm
