Xerox WorkCentre PE220 User Manual

5Printing
5-26 Xerox PE220
Sharing the Printer Locally
You can connect the printer directly to a selected computer, which is called
“host computer,” on the network.
The following procedure is for Windows XP. For other Windows OS, refer to
the corresponding Windows User's Guide or online help.
NOTE:
• Check the Operating System(s) that are compatible with your printer.
Please refer to the OS Compatibility section of Printer Specifications in
your Printer User Guide.
• If you need to know the exact name of your printer, you can check the
supplied CD-ROM.
Setting Up a Host Computer
1. Start Windows.
2. From the Start menu select Printers and Faxes.
3. Double-click your printer driver icon.
4. From the Printer menu, select Sharing.
5. Check the Share this printer box.
6. Fill in the Shared Name field, and then click OK.
Setting Up a Client Computer
1. Right-click the Windows Start button and select Explorer.
2. Open your network folder in the left column.
3. Click the shared name.
4. From the Start menu select Printers and Faxes.
5. Double-click your printer driver icon.
6. From the Printer menu, select Properties.
7. From the Ports tab, click Add Port.
8. Select Local Port and click New Port.
9. Fill in the Enter a Port Name field with the shared name.
10. Click OK and click Close.
11. Click Apply and click OK.

Xerox WorkCentre PE220 Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan, Fax
Grayscale Depth	8-bit
Standard Media Capacity	250 sheets
PC Connection	USB 2.0
Scan Resolution	600 x 600 dpi
Color Depth	24-bit
Media Size Class	A4
Max Media Size	8.5 x 14 inches
Supported Media Type	Envelopes, Transparencies, plain paper
Supported Operating Systems	Windows, Mac OS
Print Speed	Up to 22 ppm
