Xerox WorkCentre PE220 User Manual

5Printing
5-32 Xerox PE220
NOTE:
• It is necessary to claim swap partition of 300 MB or larger when working
with large scanned images.
• The Linux scanner driver supports the optical resolution at maximum.
Please refer to the scanner and copy section of Specifications in your
Printer User Guide.
• You can check your printer name in the supplied CD-ROM.
Software
• Linux Kernel 2.4 or higher
• Glibc 2.2 or higher
• CUPS
• SANE
Installing the MFP Driver
1. Make sure that you connect your machine to your computer. Turn both
the computer and the machine on.
2. When the Administrator Login window appears, type in root in the Login
field and enter the system password.
NOTE: You must log in as a super user (root) to install the printer software. If
you are not a super user, ask your system administrator.
3. Insert the printer software CD-ROM. The CD-ROM will automatically run.
If the CD-ROM does not automatically run, click the icon at the bottom
of the desktop. When the Terminal screen appears, type in:
[root@localhost root]#cd /mnt/cdrom/Linux
[root@localhost root]#./install.sh
NOTE: The installation program runs automatically if you have an autorun
software package installed and configured.
4. Click Install.

Xerox WorkCentre PE220 Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 Kbps
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan, Fax
Grayscale Depth	8-bit
Standard Media Capacity	250 sheets
PC Connection	USB 2.0
Scan Resolution	600 x 600 dpi
Color Depth	24-bit
Media Size Class	A4
Max Media Size	8.5 x 14 inches
Supported Media Type	Envelopes, Transparencies, plain paper
Supported Operating Systems	Windows, Mac OS
Print Speed	Up to 22 ppm
