YD-EM279
11
PREMIUM E-MOBILITY
●
Disassembly Flat fork cover → 88 pages
●
Disassembly bolt - arrow - .
●
Disassembly nut - arrow A - .
●
Disassembly bolt - arrow - .
●
Disassembly nut - arrow A - .
●
Disassembly the motor.
Installation
Installation is carried out in reverse order of disassembly.
Caution：
●
If the motor wiring harness is loosened and the
fixing card is damaged, it needs to be replaced.
A
A
