YD-EM279
75
PREMIUM E-MOBILITY
6.1.10 Disassembly and installation of steering bearings
6.1.10.1 Service tools
●
Open end wrench 34mm
6.1.10.2 Disassembly and installation
Disassembly
●
Park the vehicle on a horizontal road surface to
support the main bracket.
●
Close the key and pull it out.
●
Open the seat cushion and turn off the air switch.
●
Disassembly the direction handle. → Page 73
●
Dismount the steering bearing lock nut - arrow -
and Disassembly the steering bearing.
Installation
Installation is carried out in reverse order of disassembly.
6.1.11 Disassembly and installation of the front wheels
6.1.11.1 Service tools
●
Sleeve 17mm
6.1.11.2 Disassembly and installation
Disassembly
●
Park the vehicle on a horizontal road surface to
support the main bracket.
●
Disassembly nut - arrow -.
●
Disassembly the front axle - 1 -.
●
Disassembly Bolt - Arrow - .
●
Disassembly the front wheel.
Installation
Installation is carried out in reverse order of disassembly.
