Yamaha MT-01 T 2005 User Manual

ENGINE REMOVAL
5-2
ET5YU1027
CHECKING THE OIL PIPES
1. Check:
• Oil pipes
Damage → Replace.
Obstruction → Wash and blow out with com-
pressed air.
ET5YU1028
CHECKING THE OIL STRAINER
1. Check:
• Oil strainer (oil tank)
Damage → Replace.
Contaminants → Clean with engine oil.
ET5YU1019
INSTALLING THE OIL TANK
1. Install:
• Oil tank
NOTE:
Tighten the oil tank bolts in the proper tightening
sequence as shown.
T
R
.
.
Oil tank bolt
10 Nm (1.0 m·kg, 7.2 ft·lb)
1
5
7
3
2
6
8
4
10
16
15
13
11
14
12
9

Yamaha MT-01 T 2005 Specifications

General

Year	2005
Manufacturer	Yamaha
Model	MT-01 T
Category	Naked bike
Displacement	1670 cc
Bore x Stroke	97.0 x 113.0 mm
Compression Ratio	8.36:1
Fuel System	Fuel injection
Ignition	TCI
Lubrication	Wet sump
Clutch	Wet, multiple-disc
Transmission	5-speed
Final Drive	Chain
Frame	Aluminum die-cast
Front Suspension	Telescopic fork
Rear Suspension	Swingarm
Front Brakes	Double disc
Rear Brakes	Single disc
Rear Tire	190/50-ZR17
Overall Length	2185 mm
Overall Height	1105 mm
Seat Height	825 mm
Wheelbase	1525 mm
Ground Clearance	140 mm
Dry Weight	240 kg
Maximum Torque	150.3 Nm (15.3 kgf-m) @ 3750 rpm
Overall Width	800 mm
Fuel Capacity	15.0 litres
Engine Type	V-twin, four-stroke
Front Tire	120/70-ZR17
