CAMSHAFTS
5-16
EAS23750
CAMSHAFTS
Removing the camshaft sprocket cover
Order Job/Parts to remove Q’ty Remarks
Engine Refer to “ENGINE REMOVAL” on page 5-1.
1 Spark plug 4
2 Timing mark accessing screw 1
3 Crankshaft end cover 1
4 Decompression solenoid cover 1
5 Camshaft sprocket cover 1
6 Camshaft sprocket cover gasket 1
7 Dowel pin 2
For installation, reverse the removal
procedure.
LS
T
R
.
.
18 Nm (1.8 m
•
kg, 13 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
8 Nm (0.8 m
•
kg, 5.8 ft
•
Ib)
4
7
6
5
2
3
1
1
New
(6)
New
New
