ELECTRIC STARTING SYSTEM
7-9
EAS27190
TROUBLESHOOTING
The starter motor fails to turn.
NOTE:
Before troubleshooting, remove the following part(s):
1. Seat
2. Fuel tank
3. Air filter case
4. Oil tank
NG
OK
NG
OK
NG
OK
NG
OK
NG
OK
NG
OK
NG
OK
1. Check the fuses.
(Main, ignition, auto
decompression, and ECU)
Refer to CHECKING THE FUSES
on page 7-93.
Replace the fuse(s).
2. Check the battery.
Refer to CHECKING AND
CHARGING THE BATTERY on
page 7-94.
Clean the battery terminals.
Recharge or replace the battery.
3. Check the starter motor.
Refer to CHECKING THE
STARTER MOTOR on page 5-72.
Repair or replace the starter motor.
4. Check the relay unit (starting circuit
cut-off relay).
Refer to CHECKING THE
RELAYS on page 7-96.
Replace the relay unit.
5. Check the relay unit (diode).
Refer to CHECKING THE RELAY
UNIT (DIODE) on page 7-98.
Replace the relay unit.
6. Check the starter relay.
Refer to CHECKING THE
RELAYS on page 7-96.
Replace the starter relay.
7. Check the main switch.
Refer to CHECKING THE
SWITCHES on page 7-89.
Replace the main switch/immobilizer unit.
