EAS20100
SYMBOLS
The following symbols are used in this manual
for easier understanding.
NOTE:
The following symbols are not relevant to every
vehicle.
G
M
E
B
LS
M
91011
12 13 14
15 16
LT
New
T
R
.
.
123
456
78
1. Serviceable with engine mounted
2. Filling fluid
3. Lubricant
4. Special tool
5. Tightening torque
6. Wear limit, clearance
7. Engine speed
8. Electrical data
9. Engine oil
10.Gear oil
11.Molybdenum disulfide oil
12.Wheel bearing grease
13.Lithium-soap-based grease
14.Molybdenum disulfide grease
15.Apply locking agent (LOCTITE
®
).
16.Replace the part with a new one.
