4. Disassembly and reassembly
145
(9) Removing the starting motor
Remove the starting motor from the flywheel
housing.
(10) Removing the alternator
1) Loosen the alternator adjuster bolt and
remove the V-belt.
2) Removing the adjuster from the fresh water
pump, and remove the alternator from the
gear case (with distance piece).
010436-00E
Flywheel housing
Starting motor
Fresh water pump
Adjuster
Alternato
Gear case
010435-00E
