4. Disassembly and reassembly
146
(11) Removing the cooling water pipe
(seawater/ fresh water)
Seawater
inlet
Seawater pump
Heat exchanger
Mixing elbow
010390-00E
Heat exchanger
Exhaust manifold
Fresh water pump
From lube
oil cooler
010389-00E
Seawater pump
Seawater inlet
Heat exchanger
Mixing elbow
014218-00E
Heat exchanger
Fresh water pump
Fuel injection pump
A
A
Exhaust manifold
014219-00E
3JH4E
Seawater pipe
3JH4E
Fresh water pipe
4JH4-TE and 4JH4-HTE
Seawater pipe
4JH4-TE and 4JH4-HTE
Fresh water pipe
