2. Inspection and adjustment
79
3) Remove the filler cap of the fresh water cooler
by turning the cap counterclockwise 1/3 of a
turn.
Coolant tank
Fresh water pump
Drain cock
for seawate
r
Intercooler
Drain seawater from
seawater pump cover
Drain cocks for
fresh water
008792-00
J
Drain cock for
fresh water
Drain cock for
seawater
Fuel pum
p
Clutch cooler
008793-00
J
4JH4-HTE
Tabs
Filler cap
Fresh water coolerNotches
008411-01E
